Magnesia Chrome Castable
Features: Adoption of High-quality synthesized fused magnesia as raw material and specially bined together, good performance of integration with non-sticky residue. Applied to tundish metallurgy, and other parts of the copper trench.
| 项目Item 指标Index | LXTJ-A | LXTJ-B | |
| MgO(%) ≥ | 75 | 65 | |
| Cr₂O₃ (%) | ≥ | 8 | 8 |
| 体积密度(g/cm³) ≥Bulk Density | 2.95 | 2.80 | |
| 110℃烘干耐压强度(MPa)≥Drying crushing strength | 50 | 45 | |
| 1300℃烧结耐压强度(MPa)≥Sintering high crushing strength | 55 | 50 | |
| 线变化率(%) 1300℃×3h Permanent linear change | ±0.1 | ±0.2 | |
Chrome Corundum Castable
Chrome corundum castable is mainly made of high-strength refractory raw materials such as corundum and chromium oxide as aggregate and fine powder, and added with micro powder. The material has the characteristics of good volume stability, high strength, good wear resistance, corrosion resistance, erosion resistance, no cracking, no peeling, etc.
Chrome corundum castable belongs to the composite corundum castable series. It is a new type of amorphous refractory material that can be used in 2000-degree high-temperature kilns. It can be used in carbon black reactors, coal-water slurry gasifiers, incinerators, smelting furnaces, and steel-making furnaces. It is used in various high-temperature kilns such as glass drawing furnaces and so on. It has good results and has a longer service life than traditional corundum castables.
The main components of chromium corundum castable are aluminum oxide and chromium oxide. These two components can produce a corundum solid solution phase under the action of high temperature. This solid solution phase has obvious high temperature resistance, erosion resistance and wear resistance. It is used in carbon black reactors, ferroalloy kilns, and coal-water slurry gasifiers with good results.
Chromium corundum refractory castable is a castable refractory material with AL2O3 and Cr2O3 as the main components. It is a neutral refractory castable. It is composed of coarse aggregate, fine aggregate, and powder in a certain proportion, and a certain amount of binder and additives are added. The material is suitable for pouring construction and molding. During construction, add binder, coagulant and appropriate amount of water, and stir and mix to make a castable with good fluidity. When used, the ratio of coarse, medium and fine aggregates and powders to the binding agent can be adjusted as needed. The binding agents used are pure calcium aluminate cement and phosphoric acid (or aluminum dihydrogen phosphate).
Chrome corundum refractory castable has the characteristics of erosion resistance, corrosion resistance, high load softening temperature (1700℃), easy construction, good masonry density and low cost. It can be used in metallurgy, petroleum, chemical industry, building materials, machinery and other industries. Kilns and thermal equipment.
| Items | CrG1 | CrG2 | |
| Al2O3 Cr2O3 ≥ | 92 | 89 | |
| Bulk Density g/cm3 ≥ | 110℃ x 24h | 3.1 | 3.0 |
| Module of Rupture Mpa ≥ | 110℃ x 24h | 7 | 7 |
| Cold Crushing Strength Mpa ≥ | 1550℃ x 3h | 12 | 12 |
| 110℃ x 24h | 40 | 40 | |
| Reheating Linear Change % ≤ | 1550℃ x 3h | 100 | 100 |
| 1550℃ x 3h | +_0.5 | +_0.5 | |
Corundum spinel and corundum castable-RH furnace
Features: Selection of high quality raw materials and high-quality high-grade synthetic binders,additives, use of high temperature, fluidity, Thermal shock stability, strong resistance to slag erosion, for RH, VOD, AOD, LF Refining furnace and other iron and steel, nonferrous metallurgical smelter.
| 项目Item 指标Index | 刚玉尖晶石浇注料Corundum-spinel castables | 刚玉浇注料Corundum castable | |
| Al₂O₃ (%) ≥ | 80 | 90 | |
| MgO(%) ≥ | 8 | / | |
| 体积密度(g/cm³) ≥Bulk Density | 2.9 | 2.9 | |
|
耐压强度(MPa)≥ |
110℃×24h | 30 | 60 |
| 1600℃×3h | 60 | 70 | |
|
抗折强度(MPa)≥ Modules of Rupture |
110℃×24h | 5 | 6 |
| 1500℃×3h | 7 | 10 | |
| 线变化率(1500℃,%)Permanent linear change | 0~+1.0 | ±0.5 | |
| 使用温度(℃)Working Temperature | 1700 | 1700 | |
Steel fiber reinforced high alumina castables
| 产品名称 Product name 项目Item | 高铝质钢纤维增强耐火浇注料Steel fiber reinforced high alumina castables | ||
| LX-FH85 | LX-FH75 | ||
| 化 学 成 分 ( % ) Chemical composition | AlO₂ | 80 | 70 |
| 体积密度(g/cm³)Bulk Density | 110℃×24h | 2.80 | 2.60 |
| 常温耐压强度(MPa)≥Cold crushing strength | 110℃×24h | 85 | 80 |
| 1100℃×3h | 85 | 80 | |
| 常温抗折强度(MPa)2Cold modules of rupture | 110℃×24h | 15 | 12 |
| 1100℃×3h | 15 | 12 | |
| 永久线变化率(%)Permanent linear change | 1100℃×3h | ±0.4 | ±0.5 |
| 施工参考用水量(%)Water addition | 5.5-6.5 | 6.5-7.5 | |
| 使用部位Application | 水泥窑窑口、喷煤管; 窑门罩、冷却机 Outlet,burner,kiln hood,cooler | ||
Tabular alumina castables
Tabular conundum castable with high purty and high meling point of abular conundum as main raw materials, with high qually acivated alumina powder as raw materials, creep resistance of high thermal shock resistance, anti-spalling, high refractoriness, structural stabiity, high temperature properties and wear resistance increased significantty. At the same time, by increasing the silicon cartide, greatly enhancing the comosion resistance of conundum castable. Mainly usod for kilns and burmer.
| 产品名称Product name 项目Item | 板状刚玉浇注料Tabular alumina castables | |
| LX-20S | ||
| 最高使用温度(℃)Maximum Service Temp | 1700 | |
| AlO₃+SiC(%)≥ | 90 | |
| 体积密度110℃x24h, g/cm³)≥Bulk density | 3.00 | |
| 抗折强度(MPa)≥Modules of Rupture | 110℃×24h | 10 |
| 1100℃×3h | 12 | |
| 400℃×3h | 14 | |
| 耐压强度(MPa)≥Cold crushing strength | 10℃×24h | 100 |
| 1100℃×3h | 100 | |
| 1400℃×3h | 120 | |
| 线变化率(%)Permanent linear change | 1400℃×3h | ±0.3 |
| 1500℃×3h | ±0.5 | |
| 施工参考用水量(%)Water addition | 4.5-5.0 | |
| 最高使用温度(C)Maximum Service temp | 1700 | |
